HBZ320001 Carbon Cub S 2 1.3m RTF Basic

Introduction

If you've never flown a radio controlled (RC) aircraft before, the Carbon Cub S 2 is the most versatile, capable and easiest to fly scale RC airplane yet! Based on the Carbon Cub by CubCrafters, an upgraded and thoroughly modern iteration of the classic Super Cub, and equipped with Horizon Hobby's exclusive and innovative SAFE technology, this scale replica makes it possible for almost anyone to learn to fly successfully. The durable EPO airframe is equipped with an efficient brushless motor along with a telemetry-capable ESC plus a factory-installed flight controller, receiver and servos. The taildragger landing gear with oversized "tundra" style tires and a steerable tailwheel make it possible to take off from and land on a wide variety of surfaces from pavement to grass and even gravel. Or optional floats (sold separately) can be installed for takeoffs from and landings on water. Best of all, the option to add SAFE Plus^® GPS-enabled technology and the Landing Assist Sensor (LAS) makes learning to fly even easier than ever before!

Features

LEARN TO FLY SUCCESSFULLY

Welcome to the exciting world of RC (Radio Controlled) flight! If you've ever dreamed of taking to the skies, Horizon Hobby has you covered. We are committed to engineering aircraft that you can learn to fly with successfully even if you've never flown RC before. Every HobbyZone^® aircraft we offer features industry-leading design and technology developed by experts to keep you in control and learning at your own pace so you can turn your dreams of flight into a reality!

The HobbyZone^® Carbon Cub S 2 is the easiest to fly, most capable and versatile scale trainer RC airplane yet! It's equipped with exclusive SAFE^® (Sensor Assisted Flight Envelope) technology that helps to prevent overcontrol, loss of orientation and crashes so nearly everyone can learn to fly successfully. Beginner, Intermediate and Experienced modes allow you to choose the level of stability and control you need, or are ready to try, at the flip of a switch. And you can instantly return to steady flight using Panic Recovery with the push of a button in any flight mode. Oversized "tundra" tires make it possible to take off from and land on a variety of surfaces including thick grass, gravel paths, dirt trails and smooth pavement, or you can install the optional floats to fly from water—which adds to its unmatched versatility and capabilities.

The Carbon Cub S 2 is equipped with a 30-amp telemetry-capable ESC that provides a variety of real-time power system related telemetry data including motor RPM, current, battery voltage and more to compatible Spektrum^™ AirWare^™ equipped transmitters, and even approximate flight battery power remaining via multiple LEDs on the DXS transmitter included with the RTF Basic version. And you have the option to easily upgrade to SAFE Plus GPS-enabled technology that offers features such as AutoLand and Virtual Fence, along with the option to install the Landing Assist Sensor (LAS) that automatically "flares" for smoother landings, to make learning to fly—and to land safely—easier than ever!

The Ready-To-Fly (RTF) Basic version includes everything needed to fly in one box except for a battery and charger. This allows you to choose a convenient and money-saving Spektrum^™ Powerstage bundle or the separate battery and charger you prefer! Plus the included Spektrum DXS 2.4GHz transmitter can be used with other Bind-N-Fly^® (BNF) and BNF Basic aircraft after you learn to fly successfully! A BNF Basic version is also available for experienced pilots who want to use their favorite Spektrum transmitter along with batteries and chargers they may already own. And for both versions, the powerful and efficient brushless power system including a telemetry-capable ESC, flight controller, receiver and servos, are all factory-installed in the durable EPO airframe that assembles quickly and easily without the need for glue or special tools.

And the fun doesn't stop after you learn how to fly! In the Experienced Mode, the Carbon Cub S 2 is capable of performing aerobatic maneuvers including loops, rolls, inverted (upside down) flight and more. You can even use the same DXS transmitter that's included with the RTF Basic version, along with the same battery and charger you use for the Carbon Cub, to fly a variety of BNF Basic version "Next Step" aircraft including the E-flite^® T-28 Trojan 1.1m, the Valiant 1.3m and others!

You can also purchase the RealFlight Trainer Edition RC Flight Simulator and a Spektrum WS2000 Wireless Simulator Dongle (both sold separately) to fly this and other models using the transmitter included with the RTF Basic version! The simulator features many of the most popular Horizon Hobby trainer aircraft and built-in Virtual Flight Instructor lessons. This helps new pilots learn to fly successfully by practicing on a PC at home or on a laptop just about anywhere else!

Ready-To-Fly Basic Flexibility

This Ready-To-Fly (RTF) Basic version includes a Spektrum^™ DXS controller/transmitter equipped with industry-leading DSMX^® 2.4GHz technology and everything else you need to fly except for a rechargeable lithium polymer (LiPo) battery and charger for the airplane. The convenient and money-saving Spektrum^™ Powerstage 2 bundle (SPMXPSA200) includes a compatible 3S 2200mAh Smart G2 LiPo battery and an S120 USB-C Smart charger that can be used with a variety of USB power sources. Or you can choose the separate 3S 1300–2200mAh battery and compatible charger you prefer!





Telemetry Capable

The Carbon Cub S 2 1.3m is equipped with a telemetry-capable ESC that can provide a variety of real-time power system related telemetry data to compatible transmitters. This includes approximate flight battery power remaining via multiple LEDs and audible alerts from the DXS transmitter included with the RTF Basic version. It will also provide motor RPM, current, overall battery voltage and more to Spektrum AirWare^™ equipped transmitters (including the DX6e and 8e, DX6 G2/G3 and 8 G2, the DX9, the NX6, 8 and 10, the iX12, iX20 and others) while you fly.



Durable Design

Construction with advanced EPO material delivers a lightweight yet durable airframe that's tough enough to handle everyday flying punishment without getting bent out of shape. And in the unfortunate event you damage any airframe parts or components and can't repair them, a full line of replacement parts is readily available.



Easy Assembly

The Carbon Cub S 2 arrives mostly factory-assembled with the power system, servos, flight controller and receiver installed. All you need to do is finish some quick and easy final assembly, without the use of glue or special tools, and you'll be ready to fly in less time than it takes to charge a battery!



Versatile Gear Options

Thick grass, gravel paths, dirt trails; you can fly from these and many other surfaces that are impossible for most models of this size to handle. The robust landing gear is equipped with oversized tires that soak up the bumps of rough surfaces and provide excellent prop clearance. The optional float set (HBZ7390, sold separately) takes just a few minutes to install and all the necessary hardware is included with the aircraft and float set so you can fly from lakes and ponds.



Optional Flaps

Functional flaps are an option for improved slow speed handling and even shorter takeoffs and landings. This feature requires a 7+ channel computer transmitter plus a flap servo and a servo extension (sold separately).



Optional Landing Assist Sensor for Smoother Landings

The Spektrum Landing Assist Sensor (LAS) is easy to install and provides automatic "flare" control to help inexperienced pilots "grease" landings by minimizing or completely eliminating bouncing (works over many/most surfaces and provides optimum performance when flying over/landing in grass).





Easily Upgrade to SAFE^® Plus GPS-Enabled Technology

With quick and easy installation of the optional Spektrum GPS Module (SPMA3173; sold separately), you can add next-level autonomous guidance features that make it even easier to learn to fly. With SAFE Plus added, you get:

AutoLand

Activated by simply holding down a button, the advanced AutoLand function puts the airplane on a stabilized approach to land on its own near the GPS initialization point. You can even provide some directional guidance to avoid obstacles or to adjust the approach while letting the system do the rest to execute a safe landing. As your skills progress and you gain more confidence, you can take over more control inputs, eventually learning to land without any assistance from the automated system.

Holding Pattern

This beneficial SAFE Plus-exclusive feature allows you to "pause" the flight by putting the airplane into a GPS-guided holding pattern. When activated with the quick press of a button, the aircraft will automatically return to a position above the GPS initialization point and circle until the command is canceled with another quick press of the button. It's a great way to safely hand the controls off to a friend or regain visual contact if you ever lose sight of the model.

Virtual Fence

It's easy to accidentally let an RC airplane fly too far away, but with Virtual Fence, worry no more! It creates an invisible boundary the airplane won't fly past. When the plane reaches this boundary, it will automatically turn around and fly back toward the GPS initialization point. Then it will "wag" the wings to let you know when you have control again.







Flight School Qualifying Trainer

This trainer model qualifies for use in the Horizon Hobby Flight School. As a trainer, this plane needs minimal preparation to be flight-ready. It also includes SAFE® (Sensor Assisted Flight Envelope) technology to help new pilots control their models. Purchase this item along with a three-month AMA trial membership to get started. More information can be found here!

Product Specifications

Skill Level	Level 1
Wingspan	51.18" (1300 mm)
Approximate Assembly Time	Less than 1 Hour
Flaps	No
Material	EPO
Power Type	Electric
Servos	Included
Product Length	34.06" (865 mm)
Motor Size	480 Brushless Motor 960kV
Product Weight	32.2oz (913g) without Battery
Connector Type	IC3
Battery	Sold Separately
LiPo Compatibility	3S
Completion Level	Ready-To-Fly Basic
Recommended Motor Battery	3S 11.1V 1300–2200mAh LiPo with EC3 or IC3 Connector
Motor Type	Brushless
Speed Control	Included
Radio	Included
Technology	AS3X and SAFE
Receiver	Included
Charger	Sold Separately
