EFL02350 Habu SS 50mm EDF BNF Basic

The Jet For Just About Everyone

Based on one of the best first and high-performance EDF (Electric Ducted Fan) sport jet platforms ever designed — the legendary Habu — the E-flite^® Habu SS 50mm EDF is the most affordable and convenient version yet, scaled down from the popular Habu STS (Smart Trainer with SAFE^®) and SS (Super Sport) 70mm EDFs. It's the first-ever 50mm class model from E-flite, the perfect first-ever EDF for low-time RC pilots making the transition into jet flying, and one of the best-ever everyday sport jets for experienced pilots! The power system is compatible with extremely common and popular 3S 1300–2200mAh batteries and features a Spektrum^™ Avian^™ 30-amp Smart Lite ESC. The BNF^® Basic version also includes an AR631 receiver that delivers real-time telemetry data along with the benefits of exclusive AS3X^® and SAFE Select technologies — making it an ideal "next step" for anyone who has learned to fly successfully with a trainer.

Features

Easy To Fly And Extremely Fun

The E-flite^® Habu SS (Super Sport) 50mm EDF is perfect for low-time to experienced pilots looking for a hassle-free, fun to fly high-performance EDF sport jet. The unique and optimized design of its lightweight yet durable, composite-reinforced EPO airframe improves low-speed handling and slow speed performance to make it one of the easiest to fly jets EVER! Unlike other 50mm class models, it also has a functional rudder for added control and aerobatic capabilities. Inside, a Spektrum^™ Avian^™ 30-amp Smart Lite ESC and high-power brushless outrunner motor are ready to drive the 12-blade 50mm fan with a wide range of 3S batteries. Install a 1300mAh battery to keep the weight down, an 1800mAh battery for an excellent blend of performance, or a 2200mAh battery for maximum power delivery and long flight times. With Smart and non-Smart batteries, the ESC can also provide a variety of real-time power system telemetry data including motor RPM, current, battery voltage and more via compatible receivers (including the AR631) and Spektrum AirWare^™ equipped transmitters. Wide-stance tricycle landing gear with a steerable nose wheel offers great ground handling for easier takeoffs and landings on surfaces ranging from paved runways to dirt and even short grass. It's also easy to hand launch and belly land without the landing gear installed. The Habu SS 50mm EDF arrives factory-finished in a high-visibility trim scheme with the power system, servos, and receiver (BNF^® Basic version only) factory-installed. You'll be ready to fly in less time than it takes to charge a battery!

If you're completely new to flying RC (Radio Controlled) aircraft, we recommend learning to fly with one of our purpose-built trainer aircraft such as the E-flite^® Habu STS (Smart Trainer with SAFE) 70mm EDF (EFL01500). It's equipped with exclusive and innovative SAFE^® technology that makes it possible for almost anyone to learn to fly successfully!

Exclusive Technologies

The BNF Basic version is equipped with exclusive Spektrum^™ AS3X^® and SAFE^® Select technologies. AS3X works behind the scenes to smooth out the effects of wind and turbulence to deliver a locked-in feel that makes it seem like you're flying a much larger airplane. Optional-use SAFE Select offers pitch and bank angle limits along with automatic self-leveling that can be turned on and off at the flip of a switch! And if you don't want to enable the SAFE Select features, simply bind the receiver normally and only AS3X will be active.



Smart Technology

The Habu SS 50mm EDF is equipped with an exclusive Spektrum^™ Avian^™ Smart Lite ESC that can provide a variety of real-time power system related telemetry data including motor RPM, current, battery voltage and more – with Smart and non-Smart batteries – via compatible receivers (including the AR631) and Spektrum AirWare^™ equipped transmitters (including the DX6e and 8e, DX6 G2/3 and 8 G2, the DX9, NX6, 8 and 10, iX12, iX20 and others) while you fly. Plus, optional-use thrust reversing can help shorten rollout after landing and offers other special ground handling capabilities.



Popular Power

The factory-installed Spektrum^™ Avian^™ 30-amp Smart Lite ESC and high-power brushless outrunner motor can drive the 12-blade 50mm fan with a wide range of extremely common and popular 3S batteries. Install a 1300mAh battery to keep the weight down, an 1800mAh battery for an excellent blend of performance, or a 2200mAh battery for maximum power delivery and the longest flight times!



Uniquely Optimized

Jets are typically faster and harder to fly than most of their prop-driven counterparts, which can make it difficult for low-time – and sometimes even experienced pilots – to fly them. The unique and optimized airframe design of the Habu SS improves low-speed handling and slow speed performance and makes it one of the easiest to fly jets EVER!



More Capable

The lightweight yet durable composite-reinforced EPO airframe is factory-finished in a high-visibility trim scheme. And unlike other 50mm class models, it's equipped with a functional rudder for added control and aerobatic capabilities.



Gear Options

The wide-stance tricycle landing gear with a steerable nose wheel offers great ground handling for easier takeoffs and landings on a wide variety of surfaces from paved runways to dirt and even short grass. Or you can leave the landing gear off for more speed and vertical performance plus easy hand launches and landings on grass.



Easy Assembly

The Habu SS 50mm EDF arrives mostly factory-assembled with the power system, servos plus the receiver (BNF^® Basic version only) installed. All you need to do is finish some quick and easy final assembly, without the use of glue or special tools, and you'll be ready to fly in less time than it takes to charge a battery!

Product Specifications

Completion Level	Bind-N-Fly
Recommended Motor Battery	3S 11.1V 1300–2200mAh LiPo with EC3™ or IC3® Connector (sold separately)
Approximate Assembly Time	Less Than One Hour
Flaps	No
Material	EPO
Minimum Required Radio	Full-Range 4 Channel DSMX®/DSM2®
Radio	Sold Separately
Technology	Smart, AS3X and SAFE
Charger	Sold Separately
Receiver	Included
Fan Size	50mm EDF
Motor Type	Brushless - Outrunner
Speed Control	Included
Product Weight	20 oz (577g) with 3S 1300mAh LiPo Battery; 15 oz (424g) Without Battery
Power Type	Electric
Servos	Included
Product Length	30.51" (775 mm)
Motor Size	2628-4900Kv Brushless 6-Pole Outrunner
Battery	Sold Separately
Connector Type	IC3
Skill Level	Level 2 - NS
Trim Scheme Colors	White / Grey / Orange
Wingspan	27.56" (700 mm)
